#include <cxReconstructOutputValueParamsInterfaces.h>
Public Member Functions | |
DoublePropertyOutputValueParams (UsReconstructionServicePtr reconstructer) | |
virtual | ~DoublePropertyOutputValueParams () |
virtual double | getValue () const |
get the data value. More... | |
virtual bool | setValue (double val) |
set the data value. More... | |
virtual void | connectValueSignals (bool on) |
![]() | |
DoublePropertyBase () | |
virtual | ~DoublePropertyBase () |
virtual QString | getDisplayName () const =0 |
name of data entity. Used for display to user. More... | |
virtual QVariant | getValueAsVariant () const |
virtual void | setValueFromVariant (QVariant val) |
virtual QString | getUid () const |
virtual void | setGuiRepresentation (GuiRepresentation type) |
virtual GuiRepresentation | getGuiRepresentation () |
virtual QString | getHelp () const |
return a descriptive help string for the data, used for example as a tool tip. More... | |
virtual DoubleRange | getValueRange () const |
virtual double | convertInternal2Display (double internal) |
range of value More... | |
virtual double | convertDisplay2Internal (double display) |
conversion from internal value to display value More... | |
virtual int | getValueDecimals () const |
number of relevant decimals in value More... | |
![]() | |
Property () | |
virtual | ~Property () |
virtual bool | getEnabled () const |
Get the enabled/disabled state of the Property. More... | |
virtual bool | getAdvanced () const |
Get the advanced flag of the adapter. More... | |
virtual QString | getGroup () const |
Flag the adapter as part of a group. More... | |
Protected Member Functions | |
virtual double | getValue (OutputVolumeParams *params) const =0 |
virtual void | setValue (OutputVolumeParams *params, double val)=0 |
Protected Attributes | |
UsReconstructionServicePtr | mReconstructer |
![]() | |
GuiRepresentation | mGuiRepresentation |
![]() | |
bool | mEnabled |
bool | mAdvanced |
QString | mGroup |
Additional Inherited Members | |
![]() | |
enum | GuiRepresentation { grSPINBOX, grSLIDER, grDIAL } |
![]() | |
virtual bool | setEnabled (bool enabled) |
Set the enabled/disabled state of the Property. More... | |
virtual bool | setAdvanced (bool advanced) |
Set the advanced flag of the adapter. More... | |
virtual bool | setGroup (QString name) |
Flag the adapter as part of a group. More... | |
![]() | |
void | changed () |
emit when the underlying data value is changed: The user interface will be updated. More... | |
![]() | |
static PropertyPtr | findProperty (std::vector< PropertyPtr > properties, QString id) |
Abstract interface to setting one of the values in class OutputValueParams. Sublass to get a concrete class.
Definition at line 34 of file cxReconstructOutputValueParamsInterfaces.h.
cx::DoublePropertyOutputValueParams::DoublePropertyOutputValueParams | ( | UsReconstructionServicePtr | reconstructer | ) |
Definition at line 19 of file cxReconstructOutputValueParamsInterfaces.cpp.
|
inlinevirtual |
Definition at line 39 of file cxReconstructOutputValueParamsInterfaces.h.
|
inlinevirtual |
Definition at line 42 of file cxReconstructOutputValueParamsInterfaces.h.
|
virtual |
get the data value.
Implements cx::DoublePropertyBase.
Definition at line 25 of file cxReconstructOutputValueParamsInterfaces.cpp.
|
protectedpure virtual |
Implemented in cx::DoublePropertyZDim, cx::DoublePropertyYDim, cx::DoublePropertyXDim, and cx::DoublePropertySpacing.
|
virtual |
set the data value.
Implements cx::DoublePropertyBase.
Definition at line 31 of file cxReconstructOutputValueParamsInterfaces.cpp.
|
protectedpure virtual |
Implemented in cx::DoublePropertyZDim, cx::DoublePropertyYDim, cx::DoublePropertyXDim, and cx::DoublePropertySpacing.
|
protected |
Definition at line 50 of file cxReconstructOutputValueParamsInterfaces.h.
