cx::ViewCollectionWidget Class Reference

#include <cxViewCollectionWidget.h>

Inheritance diagram for cx::ViewCollectionWidget:

Signals
void	rendered ()

Public Member Functions
virtual	~ViewCollectionWidget ()
virtual ViewPtr	addView (View::Type type, LayoutRegion region)=0
virtual void	setOffScreenRenderingAndClear (bool on)=0
virtual bool	getOffScreenRendering () const =0
virtual void	clearViews ()=0
virtual void	setModified ()=0
virtual void	render ()=0
virtual void	setGridSpacing (int val)=0
virtual void	setGridMargin (int val)=0
virtual int	getGridSpacing () const =0
virtual int	getGridMargin () const =0
virtual void	enableContextMenuForViews (bool enable)=0
virtual std::vector< ViewPtr >	getViews ()=0
virtual QPoint	getPosition (ViewPtr view)=0

Static Public Member Functions
static QPointer< ViewCollectionWidget >	createViewWidgetLayout (RenderWindowFactoryPtr factory, QWidget *parent=NULL)
static QPointer< ViewCollectionWidget >	createOptimizedLayout (RenderWindowFactoryPtr factory, QWidget *parent=NULL)

Protected Member Functions
	ViewCollectionWidget (QWidget *parent)

Detailed Description

Widget for displaying Views.

This is the main class for displaying visualizations. Add Views using addView(), then add Reps to the Views.

Date

2013-11-05

2014-09-26

Author

christiana

Definition at line 39 of file cxViewCollectionWidget.h.

Constructor & Destructor Documentation

~ViewCollectionWidget()

virtual cx::ViewCollectionWidget::~ViewCollectionWidget ( )

inlinevirtual

Definition at line 46 of file cxViewCollectionWidget.h.

ViewCollectionWidget()

cx::ViewCollectionWidget::ViewCollectionWidget ( QWidget *  parent )

inlineprotected

Definition at line 70 of file cxViewCollectionWidget.h.

Member Function Documentation

addView()

virtual ViewPtr cx::ViewCollectionWidget::addView ( View::Type  type, LayoutRegion  region  )

pure virtual

Implemented in cx::ViewCollectionWidgetMixed, cx::LayoutWidgetUsingViewWidgets, and cx::ViewCollectionWidgetUsingViewContainer.

clearViews()

virtual void cx::ViewCollectionWidget::clearViews ( )

pure virtual

Implemented in cx::ViewCollectionWidgetMixed, cx::LayoutWidgetUsingViewWidgets, and cx::ViewCollectionWidgetUsingViewContainer.

createOptimizedLayout()

QPointer< ViewCollectionWidget > cx::ViewCollectionWidget::createOptimizedLayout ( RenderWindowFactoryPtr  factory, QWidget *  parent = NULL  )

static

Definition at line 36 of file cxViewCollectionWidget.cpp.

createViewWidgetLayout()

QPointer< ViewCollectionWidget > cx::ViewCollectionWidget::createViewWidgetLayout ( RenderWindowFactoryPtr  factory, QWidget *  parent = NULL  )

static

Definition at line 29 of file cxViewCollectionWidget.cpp.

enableContextMenuForViews()

virtual void cx::ViewCollectionWidget::enableContextMenuForViews ( bool  enable )

pure virtual

Implemented in cx::ViewCollectionWidgetMixed, cx::LayoutWidgetUsingViewWidgets, and cx::ViewCollectionWidgetUsingViewContainer.

getGridMargin()

virtual int cx::ViewCollectionWidget::getGridMargin ( ) const

pure virtual

Implemented in cx::ViewCollectionWidgetMixed, cx::LayoutWidgetUsingViewWidgets, and cx::ViewCollectionWidgetUsingViewContainer.

getGridSpacing()

virtual int cx::ViewCollectionWidget::getGridSpacing ( ) const

pure virtual

Implemented in cx::ViewCollectionWidgetMixed, cx::LayoutWidgetUsingViewWidgets, and cx::ViewCollectionWidgetUsingViewContainer.

getOffScreenRendering()

virtual bool cx::ViewCollectionWidget::getOffScreenRendering ( ) const

pure virtual

Implemented in cx::ViewCollectionWidgetMixed, cx::LayoutWidgetUsingViewWidgets, and cx::ViewCollectionWidgetUsingViewContainer.

getPosition()

virtual QPoint cx::ViewCollectionWidget::getPosition ( ViewPtr  view )

pure virtual

Get the position of the Upper Left corner of the view, given in qt-coordinates of this (the ViewCollectionWidget).

Implemented in cx::ViewCollectionWidgetMixed, cx::LayoutWidgetUsingViewWidgets, and cx::ViewCollectionWidgetUsingViewContainer.

getViews()

virtual std::vector<ViewPtr> cx::ViewCollectionWidget::getViews ( )

pure virtual

Implemented in cx::ViewCollectionWidgetMixed, cx::LayoutWidgetUsingViewWidgets, and cx::ViewCollectionWidgetUsingViewContainer.

render()

virtual void cx::ViewCollectionWidget::render ( )

pure virtual

Implemented in cx::ViewCollectionWidgetMixed, cx::LayoutWidgetUsingViewWidgets, and cx::ViewCollectionWidgetUsingViewContainer.

rendered

void cx::ViewCollectionWidget::rendered ( )

signal

setGridMargin()

virtual void cx::ViewCollectionWidget::setGridMargin ( int  val )

pure virtual

Implemented in cx::ViewCollectionWidgetMixed, cx::LayoutWidgetUsingViewWidgets, and cx::ViewCollectionWidgetUsingViewContainer.

setGridSpacing()

virtual void cx::ViewCollectionWidget::setGridSpacing ( int  val )

pure virtual

Implemented in cx::ViewCollectionWidgetMixed, cx::LayoutWidgetUsingViewWidgets, and cx::ViewCollectionWidgetUsingViewContainer.

setModified()

virtual void cx::ViewCollectionWidget::setModified ( )

pure virtual

Implemented in cx::ViewCollectionWidgetMixed, cx::LayoutWidgetUsingViewWidgets, and cx::ViewCollectionWidgetUsingViewContainer.

setOffScreenRenderingAndClear()

virtual void cx::ViewCollectionWidget::setOffScreenRenderingAndClear ( bool  on )

pure virtual

Implemented in cx::ViewCollectionWidgetMixed, cx::LayoutWidgetUsingViewWidgets, and cx::ViewCollectionWidgetUsingViewContainer.

---

The documentation for this class was generated from the following files:

• /mnt/bamboo/bamboo/buildagent/xml-data/build-dir/NN-RE-BU2/CX/CX/source/resource/view/View/cxViewCollectionWidget.h
• /mnt/bamboo/bamboo/buildagent/xml-data/build-dir/NN-RE-BU2/CX/CX/source/resource/view/View/cxViewCollectionWidget.cpp
